- Type of Protection: Flameproof (Explosion proof) Ex-d,
- Area Classification: Zone 1 & 2,
- Gas Groups: I, IIA, IIB and IIC (Please refer detailed product specification),
- IP Protection: Minimum IP 55 or IP 65/66,
- Apparatus standard:For Ex-d - IS 2148/1981 (Re-certification based on IEC 60079 series is under process),
- Material: Cast Aluminium Alloy LM-6,
|
- Finish: Corrosion Resistant Epoxy paint Shade 631 of IS 5,
- Glass: Heat and Impact Resistance and Toughened Glass,
- Gasket:Endless Neoprene minimum 3 mm dia,
- Hardware: All flame path - SS Allen Bolt or threaded. All other SS,
- Mounting:Wall / Structure mounting arrangement using Bolt of minimum M8.
- Voltage: 50 Hz AC supply I or III phase Maximum 500V,
- Cable Entry Size / No.: Based on Equipments various size and Quantity in BSCon. Thread,
|
- Equipment Type: Control Station like - Push Button with or without Indicator / Selector Switch / Measuring Instruments, Limit Switch, Gong Bell, Hooter, Direct ON Line Starter, Switch (ON/OFF, Reversing, Change Over, and Selector), Switch Fuse Unit etc.,
- Earthing: External 2 Nos. of size M6 & Internal 1 No. of size M6,
- Wire Size: As per current Rating minimum 1.5 sq. mm. Cu flexible PVC Insulated,
- Accessories: (OPTIONAL) Cable Gland, Stopping Plug and Mounting Hardware
|
|
PEW/DI/029 Ex-d/WP Control Station consists of 3 Nos. Push Button(1 No or 1NC contact), Selector Switch and Ammeter (72X72 mm) 5A 230V AC.
|
|
|
PEW/LS/033 Ex-d/WP Limit Switch with 1NO + 1 NC contact Element Top Push Roller Type (Direct Entry)
|
|
|
PEW/LS/037 Ex-d/WP Limit Switch with 1NO + 1 NC contact Element Top Push Roller Type (Direct Entry)
|
|
